AL9CU Terminal Lugs

Termination of either aluminum or copper conductors
AL9CU for low to medium voltage up to 35kV
For indoor and outdoor use
486B listed AL9CU
UL File No. E498659

Copper Compression Splice – Standard Barrel 750 MCM
Manufactured from high conductivity seamless copper tubing
Tin-plated to inhibit corrosion
Beveled entry for easy cable insertion
Inspection window ensures full cable insertion
Color coded barrel is marked with die index number
Suitable for voltages up to 35 KV
45° and 90° angles are UL listed and CSA certified
For 45° or 90° bent tongue, add suffix “-45” for 45 deg. or “-90” for 90 deg. to the catalog number
UL listed per UL486A-B and CSA certified per C22.2 No. 65 for power applications
UL listed for grounding, bonding, and direct burial applications per UL467
CSA certified for grounding, bonding, and direct burial application per C22.2 No. 41
UL listed and CSA certified with Penn-Union, Burndy, T&B, Huskie, Greenlee and Versa-Crimp® style tooling

For use with either copper or aluminum conductors
Rated 600V at 90°C
486B Listed AL9CU
